Technical Specification:

• ABC indicator: A
• Associated standards: BS EN 60947-3 + BS EN 60269-1
• Rated voltage: 220-415V
• Rated current: 200A
• Frequency: 50-60Hz
• Wiring system: 3 pole
• Min. switch contact gap: 4mm
• Ambient operating temperature:
• -5 to 40°C (24hour average not exceeding 25°C)
• Degree of protection: IP65
• Nature of supply: AC
• Extension possible: yes
• Type of door: steel
• Material housing: steel
• Plate thickness cabinet: 1.2
• Plate thickness door/cover: 1.2
• Mounting method: surface
• With mounting plate: yes
