Product Details

• Mounting method: Surface mounted


• Number of modules: 18


• Number of available modules: 12


• Number of rows: 1


• Standard: BS EN 61439-3


• Number of phases: Single phase


• Rated current (InA) [ A ]: 100


• Rated operational voltage (Ue) [ V ]: 230


• Type of current; AC


• Frequency (f) [ Hz ]: 50


• Rated insulation voltage (Ui) [ V ]: 500


• Rated impulse withstand voltage (Uimp) [ kV ]: 4


• Rated short-time withstand current (Icw) [ kA ]; 10


• Rated conditional short-circuit current (Icc) [ kA ]: 16


• Overvoltage category: III


• Pollution degree: 2


• Location type: Indoor


• Altitude [ Meter ]: < 2000


• Ambient air temperature for operation:
  • Minimum [ °C ]: -5
  • Maximum [ °C ]: +40


• Ambient air temperature for storage:
  • Minimum [ °C ]: -40
  • Maximum [ °C ]: +75
