Product Description



• Rated Current: 16A



• Fault Current Rating: .03 A



• Voltage Type: Ac



• Voltage Rating: 240 V - 240 V



• Rated Operational Voltage (Ue) - Max: 240 V



• Rated Insulation Voltage (Ui): 500 V



• Rated Impulse Withstand Voltage (Uimp): 4 Kv



• Frequency Rating: 50/60 Hz



• Leakage Current Type: A



• Rated Short-Circuit Breaking Capacity (En 60947-2): 0 Ka



• Rated Short-Circuit Breaking Capacity (En 61009): 10 Ka



• Rated Short-Circuit Breaking Capacity (En 61009-1): 10 Ka



• Rated Short-Circuit Breaking Capacity (Iec 60947-2): 0 Ka



• Surge Current Capacity: .25 Ka



• Disconnection Characteristic: Undelayed



• Release characteristic: C



• Overvoltage Category: III



• Pollution Degree: 2
