Fusebox F2007M 7-way Consumer Unit (100A Main Switch)

Name: Fusebox F2007M 7-way Consumer Unit (100A Main Switch)
Brand: Fusebox
SKU: F2007M
Price: 30.9 GBP
Availability: InStock

Roll over image to zoom in Click on image to zoom

Fast Delivery

Product Details

NUMBER OF USABLE WAYS	7
PART NUMBER WITH T2 SPD	F2007M
WEIGHT (1PC) Kg	2.8
DIMENSIONS (HxWxD)mm	259x234x113
DOUBLE BANK	N
TAIL CLAMP COMPATIBLE (ACCF)	Y
STANDARD	EN 61439-3
RATED VOLTAGE (Un/AC)	230V
FREQUENCY (Hz)	50/60
PROTECTION DEGREE (IP)	2XC
MAXIMUM TERMINAL BAR CAPACITY	16mm ²
TERMINAL BAR TIGHTENING TORQUE (Nm)	2
DEVICE MOUNTING	35mm DIN RAIL
MATERIAL	1mm ELECTRO GALVANISED STEEL (ZINC)
FINISH	RAL 9001 POWDER COATED SMOOTH FINISH
KNOCKOUTS	SELECTION 20mm - 40mm
ACCESSORY PACK	CIRCUIT IDENTIFICATION LABELS / GROMMET STRIP

You'll probably need the following items

Fusebox F20xx RCBOs
Fusebox RTA063230B 32A RCBO 6kA 1 pole (B CURVE) Type A £9.55
Fusebox RTA060630B 6A RCBO 6kA 1 pole (B CURVE) Type A £9.55
Fusebox RTA061630B 16A RCBO 6kA 1 pole (B CURVE) Type A £9.55
Fusebox RTA062030B 20A RCBO 6kA 1 pole (B CURVE) Type A £9.55
Fusebox RTAMB06 6A Mini-RCBO 6kA 2 pole (B Curve) Type A £13.50
Fusebox RTAMB32 32A Mini-RCBO 6kA 2 pole (B Curve) Type A £13.50
Fusebox RTAMB16 16A Mini-RCBO 6kA 2 pole (B Curve) Type A £12.15
Fusebox RTA064030B 40A RCBO 6kA 1 pole (B CURVE) Type A £9.55
Fusebox RTAMB20 20A Mini-RCBO 6kA 2 pole (B Curve) Type A £12.15
Fusebox RTAMB40 40A Mini-RCBO 6kA 2 pole (B Curve) Type A £12.15
Fusebox RTA061030B 10A RCBO 6kA 1 pole (B CURVE) Type A £9.55
Fusebox RTA064530B 45A RCBO 6kA 1 pole (B CURVE) Type A £9.95
Fusebox RTA062530B 25A RCBO 6kA 1 pole (B CURVE) Type A £9.95
Fusebox RTAMB10 10A Mini-RCBO 6kA 2 pole (B Curve) Type A £12.15
Fusebox RTA065030B 50A RCBO 6kA 1 pole (B CURVE) Type A £9.95
Fusebox RTAMB25 25A Mini-RCBO 6kA 2 pole (B Curve) Type A £12.15
Fusebox RTAMB32BD Bi-Directional MINI 32A B RCBO 1P+N (sw) 30mA 6kA £14.50
Fusebox F20xx MCBs
Fusebox MT06B061 6A 6kA 1 pole B CURVE MCB £1.52
Fusebox MT06B321 32A 6kA 1 pole B CURVE MCB £1.52
Fusebox MT06B161 16A 6kA 1 pole B CURVE MCB £1.52
Fusebox MT06B201 20A 6kA 1 pole B CURVE MCB £1.52
Fusebox MT06B401 40A 6kA 1 pole B CURVE MCB £1.52
Fusebox MT06B501 50A 6kA 1 pole B CURVE MCB £1.70
Fusebox MT06B631 63A 6kA 1 pole B CURVE MCB £1.90
Fusebox MT06B101 10A 6kA 1 pole B CURVE MCB £1.70
Fusebox AFDDs
Fusebox AFDD063230B 32A, 2-Pole, 30mA Combined AFDD + RCBO £72.95
Fusebox AFDD062030B 20A, 2-Pole, 30mA Combined AFDD + RCBO £72.95
Fusebox AFDD061630B 16A, 2-Pole, 30mA Combined AFDD + RCBO £72.95

Optional Extras
1M Brown 6181Y25.0mm Flexi Meter Tails Double Insulated Cable £3.98
1M Blue 6181Y25.0mm Flexi Meter Tails Double Insulated Cable £3.98
1M of 6491X16.0mm Single Insulated Earth-Conduit Wiring £2.69
Fusebox G32T 32mm TAIL GLAND for 25mm2 Live & Neutral, and 16mm2 Earth (QTY 1) £2.24
