Product Details

• Type of pole 1P+N

• Curve C
• Rated current 6 A

• Residual current type A

• Rated short-circuit breaking capacity Icn AC according to IEC 60898-1 6 kA

• Rated insulation voltage Ui 440 V

• Rated impulse withstand voltage Uimp 4000 V

• Max. operating voltage 264 V

• Rated operational voltage Ue 230 - 230 V

• Overvoltage category according to IEC 60947-1 3
• Electric endurance in number of cycles 10000

• Number of mechanical operations 20000
• Cross-section of input with screws, for flexible conductors 1 - 10 mm²

• Cross-section of input with screws, for massive conductors 1 - 16 mm²
• Height 85 mm

• Width 17.70 mm

• Depth 70 mm
