Product Details

• Type of pole: 1P+N

• Curve: C
• Rated current: 20 A

• Residual current type: A

• Rated short-circuit breaking capacity Icn AC according to IEC 60898-1: 6 kA

• Rated insulation voltage Ui: 440 V

• Rated impulse withstand voltage Uimp: 4000 V

• Max. operating voltage: 264 V

• Rated operational voltage Ue: 230 - 230 V

• Overvoltage category according to IEC 60947-1: 3
• Electric endurance in number of cycles: 10000

• Number of mechanical operations: 20000
• Cross-section of input with screws, for flexible conductors: 1 - 10 mm²

• Cross-section of input with screws, for massive conductors: 1 - 16 mm²
• Height: 85 mm

• Width: 17.70 mm

• Depth: 70 mm
