WX9 is an intake / extract wall fan suitable for installations in pubs, restaurants, offices, kitchens, factories, schools and shops.

The fan comes complete with a corrugated plastic wall liner and is suitable for installations of wall thickness  275 to 375mm.

WX9 has a 2 speed extract rate of 600 & 693 m3/hr and a 2 speed intake rate of 418 & 459 m3/hr. Reversing the fan is achieved with a FR22/30 controller.

The fan includes a silent integral electro-thermal shutter to prevent backdraughts.

For safety, a finger-guard is integrated into the ultra-slim high gloss ABS fascia and the exterior wall grille design. The fan includes a positive plug and socket assembly provides a means of isolation.

Technical Specifications:

• Protection Rating: IPX4 (4)

• Model Number: WX9

• Warranty: 2 years

• Dimensions (mm): Depth 180 × Height 512 × Width 432 × Length 375

• Weight: 5.57 kg

• Material/Finish: White, glossy ABS

• Humidistat: No

• Timer: No
